CDF2
Wukai
1. Overview
The CDF2 on-load tap-changer motor-drive unit is mainly used as a mechanism to drive and control the tap-changer action, so that the tap-changer switches from one tap position to another, thus achieving voltage regulation.
The mechanical and electrical components required to operate the on-load tap-changer are installed in the motor drive unit and electrical interlocking circuits are used.
Generally, the motor-drive unit is supplied as an accessory to the on-load tap-changer unit as a complete set.
2. Technical data
Serial No. | Classification features | Data | |
1 | Motor parameters | Rated power(W) | 370 |
2 | Rated voltage(V) | 380(three-phase) | |
3 | Rated current(A) | 1.1 | |
4 | Rated frequency(HZ) | 50 | |
5 | Rotate speed(r.p.m.) | 1400 | |
6 | Output shaft drive torque, N.m. | 45 | |
7 | Tap-change output shaft revolutions per stage | 2 | |
8 | Tap-change handle revolutions per stage | 30 | |
9 | Tap-change operation time per stage(s) | 4.5 | |
10 | Control circuit and heater voltage(V) | 220 | |
11 | Control loop excitation power(VA) | At the start of the operation | 52 |
12 | During the operation | 16 | |
13 | Heater power(W) | 150 | |
14* | Control circuit frequency withstand voltage(kV/1min) | 2.5 | |
15 | Motor-drive unit case protection class | IP54 | |
16 | Mechanism life(million cycles) | 50 | |
17 | Weight(kg) | 75 | |
*Excluding motors, circuit breaker auxiliary contacts, and cable receptacles
3. Conditions of use
I The temperature of the air medium around the motor-drive unit is -25℃ at the lowest and +55℃ at the highest.;
I The altitude at which the motor-drive unit is used does not exceed 1000m above sea level;
I The inclination of the mounting axis of the motor-drive unit to the vertical plane does not exceed 5%;
I There should be no serious dust and corrosive or explosive gas around the motor-drive unit.
4. Dimensional illustration
 |  |  |
1. Overview
The CDF2 on-load tap-changer motor-drive unit is mainly used as a mechanism to drive and control the tap-changer action, so that the tap-changer switches from one tap position to another, thus achieving voltage regulation.
The mechanical and electrical components required to operate the on-load tap-changer are installed in the motor drive unit and electrical interlocking circuits are used.
Generally, the motor-drive unit is supplied as an accessory to the on-load tap-changer unit as a complete set.
2. Technical data
Serial No. | Classification features | Data | |
1 | Motor parameters | Rated power(W) | 370 |
2 | Rated voltage(V) | 380(three-phase) | |
3 | Rated current(A) | 1.1 | |
4 | Rated frequency(HZ) | 50 | |
5 | Rotate speed(r.p.m.) | 1400 | |
6 | Output shaft drive torque, N.m. | 45 | |
7 | Tap-change output shaft revolutions per stage | 2 | |
8 | Tap-change handle revolutions per stage | 30 | |
9 | Tap-change operation time per stage(s) | 4.5 | |
10 | Control circuit and heater voltage(V) | 220 | |
11 | Control loop excitation power(VA) | At the start of the operation | 52 |
12 | During the operation | 16 | |
13 | Heater power(W) | 150 | |
14* | Control circuit frequency withstand voltage(kV/1min) | 2.5 | |
15 | Motor-drive unit case protection class | IP54 | |
16 | Mechanism life(million cycles) | 50 | |
17 | Weight(kg) | 75 | |
*Excluding motors, circuit breaker auxiliary contacts, and cable receptacles
3. Conditions of use
I The temperature of the air medium around the motor-drive unit is -25℃ at the lowest and +55℃ at the highest.;
I The altitude at which the motor-drive unit is used does not exceed 1000m above sea level;
I The inclination of the mounting axis of the motor-drive unit to the vertical plane does not exceed 5%;
I There should be no serious dust and corrosive or explosive gas around the motor-drive unit.
4. Dimensional illustration
| | |
